Χαρακτηριστικά:

• Video/Audio Input
• Audio Input: | 4-ch
• Video Compression: | H.265+/H.265/H.264+/H.264
• Analog and HD-TVI video input: | 16-ch,BNC interface (1.0Vp-p, 75 Ω)connection
• Supported camera types: | Support HDTVI input: 5MP,4MP,3MP,1080P/25Hz, 1080P/30Hz,720P/25Hz, 720P/30Hz, 720P/50Hz, 720P/60Hz,
• Support AHD input: 1080P/25Hz, 1080P/30Hz, 720P/25Hz, 720P/30Hz
• Support CVI input: 1080P/25Hz, 1080P/30Hz, 720P/25Hz, 720P/30Hz
• Support CVBS input
• Video Input Interface: | BNC (1.0 Vp-p, 75Ω)
• Audio Compression: | G.711u
• Audio Input Interface: | 4-ch, RCA (2.0 Vp-p, 1 KΩ)
• Two-way Audio: | 1-ch, RCA (2.0 Vp-p, 1 KΩ), (using the 1st channel of audio input)
• Video/Audio Output
• CVBS Output: | 1-ch,BNC(1.0Vp-p,75Ω),resolution:PAL:704x576,NTSC:704x480
• HDMI/VGA Output: | VGA: 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
• HDMI: 1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
• Recording resolution: | 5 MP/4 MP/3 MP/1080p/720p/WD1/4CIF/VGA/CIF
• Frame Rate: | Main stream:
• 5 MP@12fps/4 MP@15fps/3 MP@18fps
• 1080p/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)
• Sub-stream:
• WD1/4CIF/CIF@25fps (P)/30fps (N)
• Video Bit Rate: | 32 Kbps-10 Mbps
• ]Stream Type: | Video/Video&Audio


• wo-way Audio: | 1-ch, RCA (2.0 Vp-p, 1 kΩ) (using the audio input)
• Audio Output: | 1-ch RCA(Linear, 1kΩ)
• Audio Bit Rate: | 64kbps
• Dual Stream: | Support
• Playback Resolution: | 5MP/4MP/3MP/1080p/720p/VGA/WD1/4CIF/CIF/QVGA/QCIF
• Synchronous Playback: | 16-ch
• Network management
• Remote connections: | 128
• Network protocols: | TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
• Hard Disk Driver
• Interface Type: | 2 SATA Interfaces
• Capacity: | Up to 8 TB capacity for each disk
• External Interface
• Network Interface: | 1; 10M / 100M / 1000M self-adaptive Ethernet interface
• USB Interface: | 1 USB 2.0 Interface
